| System |
| Main Processor |
MC6630 |
| Operating System |
Embedded LINUX |
| Video |
| Input |
Normal Mode: Analog: 8*(TVI/AHD: 5M@12fps;
AHD/TVI/CVI: 4M@15fps; AHD/TVI: 3M@18fps; AHD/TVI/CVI: 1080P/720P;
Analog: 960H)
Analog+Network: 2*Analog(5MP)+7*network(MAX 5MP),
4*Analog(5MP)+5*
network(MAX 5MP),6*Analog(5MP)+3*network(MAX 5MP)
Network: 16*5MP/4MP/3MP/1080P/960P/720P
(Total incoming bandwidth<=48M) |
| Input |
8CH BNC |
| Signal Type |
Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network |
| Output |
1HD,1 VGA, CVBS |
| Audio |
| Input |
2 Channel, RCA,,support AOC |
| Two-way Audio |
NO |
| Output |
1 Channel, RCA |
| Alarm |
| Sensor Input |
4 CH |
| Output |
1 CH |
| Motion Detection |
8 Channel(max 16 Channel in pure network mode) |
| Trigger Events |
Recording, Email, Screen tips, Buzzer, Push notifications(motion detection) |
| Email Alarm |
Send Image to The Designated E-mail |
| AI Function |
| Face Comparison |
YES |
| PTZ |
| Interface |
RS485 |
| Protocol |
Pelco-D, Pelco-P |
| Baud Rate |
110~921600 |
| Address |
0~255 |
| Display |
| VGA |
Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720 60Hz,
1024 × 768/60Hz |
| HD Output |
Resolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz |
| Display Split |
16 Channel/9 Channel/8 Channel/4 Channel / 1Channel |
| Privacy Masking |
3 Rectangular Zones (Each camera) |
| OSD |
Camera title, Time, Video loss, Alarm, Motion detection, Recording |
| Recording |
| Video Compression |
H.265+/H.265/H.264+/H.264 |
| Audio Compression |
G.711U/G.711A |
| Resolution |
5MP_Lite(1296×1952),4MP_Lite(1280×1440),3MP_Lite(1024×1536),
1080N(960×1080),720P(1280×720),960H(P:960×576/N:960×480) |
| Video Quality |
Lowest/Low/Ordinary/Good/Better/Best |
| Record Rate |
Analog: PAL: 5MP_Lite(1296×1952 8*6fps),4MP_Lite(1280×1440 8*8fps),
3MP_Lite(1024×1536 8*10fps),1080N(960x1080 8*15fps),
720P(1280×720 8*15fps), 960H(960×576 8*25fps)
NTSC:5MP_Lite(1296×1944 8*6fps),4MP_Lite(1280×1440 8*8fps),
3MP_Lite(1024×1536 8*10fps),1080N(960x1080 8*15fps),
720P(1280×720 8*15fps), 960H(960×576 8*30fps)
Pure IP(H.265):
PAL: 5MP@8×25fps,4MP@12x25fps,3MP@12×25fps,1080P@12×25fps,
960P@12×25fps,720P@12×25fps,D1@12×25fps
NTSC: 5MP@8×30fps,4MP@12×30fps,3MP@12×30fps,1080P@12×30fps,
960P@12×30fps, 720P@12×30fps, D1@12×30fps |
| Record Mode |
Manual\\Timer\\Motion Detection\\Alarm Input |
| Playback & Backup |
| Decode Capability |
2CH 1080P@30fps |
| Sync Playback |
Pure Analog: 4CH 960H@25fps, 4CH 720P@15fps, 4CH
1080N@15fps, 4CH 5M_LITE@6fps, 4CH 4M_LITE@8fps,
4CH 3M_LITE@10fps;
Mixture mode: 4CH 720P@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps
Pure Network: 4CH 720P@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps |
| Remote Playback |
4 Channel / 1Channel |
| Search Mode |
ALL,Channel,Manual,Time,Date,Motion Detection,Alarm,Motion and Alarm |
| Playback Functions |
Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back,
Digital Zoom, Full screen |
| Smart Phone Playback |
4 Channel |
| Backup Mode |
USB Device(with fomat FAT 32 )/Network/FTP |
| Network |
| Interface |
1 RJ45 10M/100M Adaptive Ethernet Interface |
| Network Functions |
TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTP, RTSP, RTCP |
| DDNS |
Dyndns,changeip,no-ip,Oray,A-PRESS,MYQSEE,SKDDNS,SMART-EYES,
ZEBEYE,HDPROVN |
| Web Browser |
Edge,IE8-11, Google Chrome , Firefox ,Safari |
| CMS Software |
Support Windows 7/ Windows 8/Windows 10 |
| Extra Stream |
CIF/D1(1-12fps) |
| Smart Phone |
iPhone, ipad, Android ,Android pad |
| Hard Disk Driver |
| Interface Type |
1 SATA Interface |
| Capacity |
1 SATA Hard Disk (2.5\"/3.5\" SATA, Up to 8TB) |
| General |
| Language |
Simplified Chinese,Traditional Chinese, English, Polish, Czech, Russian,
Thai, Hebrew, Arabic, Bulgarian, Japanese, German,
French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian,
korean, Dutch, Greek, Vietnamese, |
| UTC Control |
YES |
| USB Interface |
2 USB 2.0 Interfaces |
| Power consumption |
DC 12V/2A <=6W (Without Hard Disk) |
| Working Environment |
-10~55?/10~90% |
| Dimension (W×D×H) |
260*215*43(mm) |
| Weight |
2kg (Without HDD) |
