TECHNICAL DATA
Model | VALUE 500W |
---|---|
Article no. | APB-500B8 |
EAN code | 4710713230569 |
Weight (without/with package) | 1.22kg / 1.35kg |
AC Input | 200-240V / 4.0A |
Frequency | 47 - 63Hz |
+5V | 17.0A |
+3,3V | 18.0A |
+5V & +3,3V combined | 110W |
+12V1 | 38.0A |
+12V2 | -- |
+12V1, +12V2 combined | 456W |
P.F. | >0,9 |
-12V | 0,3A / 3,6W |
+5VSB | 2,5A / 12,5W |
Maximum Power | 500W |
20+4 PIN ATX | 1 |
---|---|
8 PIN EPS (4+4) | 1 |
8 PIN PCIe (6+2) | 1 |
SATA | 3 |
MOLEX/FLOPPY | 2/1 |
20+4 PIN ATX | 500 |
---|---|
8 PIN EPS (4+4) | 350 |
8 PIN PCIe (6+2) | 350 |
SATA | 350/150/150 |
MOLEX/FLOPPY | 350/150/150 |
ATX12V Version | ATX 12V 2.3 |
---|---|
Efficiency | 80+ White (230V Only) |
Dimension (DxWxH) | 140 mm x 150 mm x 87 mm |
PFC | Active PFC (0,9) |
Fan | 120mm silent fan |
Security | AFC (Automatic Fan speed Control) OPP (Over Power Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection) |
