Senzori Starlight visoke osetljivosti 0,005Lux, za postizanje odličnih performansi u situacijama slabog osvetljenja koje koriste IR osvetljenje. Rešenje pokrec?e 3DNR smanjenje šuma i Sense-Up zatvarač male brzine. Široki dinamički opseg (WDR) od 120 dB rešava svaku situaciju pozadinskog osvetljenja ili visokog svetlosnog kontrasta.
Specifikacije:
Image Sensor | 2.0 megapixel progressive scan CMOS |
Max. Resolution | 1920 (H) ×1080 (V) |
Min. Illumination | 0.005 Lux@(F1.2, AGC ON), 0 Lux with IR |
Shutter Time | PAL: 1/25 s to 1/50, 000 s<br/>NTSC: 1/30 s to 1/50, 000 s |
Day & Night | IR cut filter |
Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
Signal System | PAL/NTSC |
Lens Type | 2.7 mm to 13.5 mm |
Focal Length & FOV | 102° to 31° |
Lens Mount | ? 14 |
Image Parameters Switch | STD/HIGH-SAT |
Image Settings | Brightness, Sharpness, 3D DNR, Mirror, Smart IR |
Frame Rate | PAL: 1080p@25fps<br/>NTSC: 1080p@30fps |
Day/Night Mode | Auto/Color/BW (Black and White) |
Wide Dynamic Range (WDR) | >= 120 dB |
Image Enhancement | Yes |
Privacy Mask | ON/OFF, 4 programmable privacy masks |
Noise Reduction | Level 1 to 10 |
White Balance | ATW/MWB |
AGC | High/Medium/Low |
Video Output | TVI/AHD/CVI/CVBS |
Motion Detection | 4 programmable motion areas |
Material | Front cover: Metal<br/>Main body: Plastic<br/>Bracket: Metal |
Dimension | 84.5 mm × 92 mm × 255.1 mm (3.33\" × 3.62\" × 10\") | Approx. 695 g (1.53 lb.) |
Operating Condition | ‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
Communication | Up the coax, Protocol: Safire-C (TVI output) |
Language | English |
Power Supply | 24 VAC ±15%, 12 VDC ±20%<br/>*You are recommended to use one power adapter to supply the power for one camera. |
Consumption | Max. 9.7 W |
IR Range | Up to 70 m |
Protection | IP67 |
